19,600 Gallon Corn Syrup Tank Car

This 19,600 gallon coiled and insulated tank car has been designed with a 286,000 lbs gross rail load and meets the AAR 211A100W1 specification for the transportation of corn syrup and other like commodities. Various options for loading/unloading valve configurations are available depending on the service requirements.

19600 Gallon Corn Syrup tank car technical drawing.


Length, Over Pulling Faces 42′-6.5″
Length, Over Truck Centers 29′
Width, Extreme 10′-8″
Height, Extreme 15′-6″
Tank, Outside Diameter 9′-10.75″
Tank, Outside Length 36′-5.875″
Clearance AAR Plate C


Light Weight 65,500 lbs
Load Limit 220,500 lbs
Gross Rail Load 286,000 lbs
Capacity 19,600 gal

Curve Negotiability Radius

Uncoupled 150′
Coupled to Base Car 153′
Coupled to Like Car 150′
